Bone Grafts and Bone Substitutes

Fractures, tumors, or infections can create significant bone loss with large bony defects. These may produce disabling injuries which can limit healing, affect weight bearing, and lead to loss of joint or limb function. To fill in these bony voids and promote bony healing, bone grafts are frequently used. Orthopedic surgeons perform at least 500,000 bone-grafting procedures annually in the United States alone. Bone grafting may be done immediately after an injury or after an interval during which the host site is prepared for the grafting (Ruedi, 2007; Parikh, 2002).

The best bone grafts are taken directly from the patient, so-called autogenous (autograft) bone grafting. Such grafts are composed of cancellous, corticocancellous, or cortical bone. The graft is either a free graft of bone with no attached soft tissue or a vascularized graft of bone with attached muscle and subcutaneous tissue (figure: fibular mandibular reconstruction; figure: calcaneus iliac crest autograft). The most frequent donor site for autogenous cancellous bone grafting is the iliac bone. Although autogenous bone grafting is the preferred method and bone graft standard, it has significant limitations. These include finding a large enough supply of bone without producing significant donor site morbidity and the inability of the autogenous graft tissue to be fabricated into customized forms.

Bone graft harvesting is sometimes performed using a reamer/irrigator/aspirator (RIA) for intramedullary reaming and bone harvesting (figure: DePuy Synthes Reamer/Irrigator/Aspirator (RIA)). Reaming is frequently performed to enlarge the medullary canal in a long bone so a prosthesis or intramedullary rod (nail) can be inserted. At the same time, bone graft harvesting may be performed; or, the procedure's primary purpose may be for harvesting of bone to fill an area of bone loss elsewhere, typically from a severe fracture. An RIA apparatus is designed to reduce intramedullary pressure, reduce potential fat embolism, and potentially removed infected tissue in cases of osteomyelitis (DePuy Synthes, 2017). The harvested material from such a system is finely morselized autogenous bone and bone marrow.

Allografts (tissue grafts between donor and recipient of the same species but of disparate genotypes) are also commonly used (figure: cadaver limb sparing allograft; figure: tibia allografts). These represent treated cadaver bone from the donor bone bank. The disadvantages associated with allografts include possible disease transmission, immunogenicity concerns, poor biologic and mechanical properties, increased cost, and unavailability worldwide due to financial and cultural issues (Ruedi, 2007; Hunter, 2003; Parikh, 2002).

The considerable limitations associated with autografts and allografts have prompted increased interest in alternative bone graft substitutes. The development and use of bone graft substitutes is a burgeoning field (Beaman, 2006). Indications for use of bone graft substitutes include fracture augmentation, vertebroplasty, augmentation of defects associated with benign or malignant bone lesions, fracture nonunion, and osteomyelitis (figure: enchondroma treatment; figure: buttress plate with bone substitute; figure: metastatic renal cell carcinoma treatment).

The main types of commercially available bone graft substitutes are demineralized allograft bone matrix, ceramics and ceramic composites, composite grafts of collagen and mineral, coralline hydroxyapatite, calcium phosphate cement, bioactive glass, and calcium sulfate (Hunter, 2003; Parikh, 2002; Larsson, 2002; Petruskevicius, 2002; Wilkins, 1999; Robinson, 1999; Ladd, 1999; Beaman, 2006; Bhatt, 2012). These are fairly common and can resemble a normal bony structure (figure: Puddu titanium plate with hydroxyapatite bone graft wedge). Recent preclinical and bio-mechanical studies with bioactive cements are also promising (Hunter, 2003; Larsson, 2002; Kurien, 2013).

For infected fracture sites as well as for treatment of bone infections, antibiotic beads and antibiotic spacers or antibiotic rods are frequently used. The beads, spacers, and rods are typically composed of polymethyl methacrylate cement containing an antibiotic which diffuses locally into the infected bone when the beads, spacers, or rods are packed into the region of infection. The bead packing cement material also provides mechanical support in areas of missing or weakened bone (figure: antibiotic beads). Cement impregnated antibiotic spacers and antibiotic paste are used mainly after resection of infected joint arthroplasty sites. Antibiotic impregnated calcium sulfate pellets are also used in the treatment of osteomyelitis (Sherry, 2001).

In many cases it can be difficult to differentiate between autogenous bone grafts and allografts. It is also often difficult to differentiate between the various bone substitutes, autogenous or allogenic bone grafts, and antibiotic impregnated cement grafts if sufficient history is not supplied. One should be aware of these different possibilities and recognize when there has been placement of a bone-like structure or material that is probably not a bony fragment from the region of injury, tumor, or infection. Deciding between the various possibilities of bone grafts, bone substitutes, and antibiotic impregnated cement materials can sometimes be helped by the radiographic appearance of the bony site and the clinical picture.

In additon to bone loss in cases of trauma, infection, or tumor, necessitating bone grafting or use of artificial bone substitute, there is often poor bony healing. Even in situations where there is no loss of bone stock, there may be poor or delayed bony healing. Electronic bone stimulators are frequently used after spinal surgery. A simular approach, also known as bone growth therapy, can be used to treat extremity fractures. Bent or broken bone generates a low level electrical field which is thought to be part of the natural bone healing process. The bone stimulators used after spinal surgery and similar devices used in the extremities stimulate the healing with low-level pulses of electromagnetic energy, creating a low-level pulsed electromagnetic field (PEMF).

Spinal bone stimulators are most commonly used for patients with multi-level spine fusions, patients having revision spine surgery after a failed fusion, and patients with a smoking history. These patients are less likely to have a solid bony fusion. Patients who have extremity fractures with extensive soft tissue and vascular damage, patients with diabetes, patients with recent steroid therapy, patients with osteoporosis, and patients who smoke are more likely to have fracture nonunion or delayed healing.

Spinal bone stimulators have traditionally been implanted (internal stimulators), but they can be worn on the outside of the spine (external stimulators) (figure: internal spinal bone stimulator). External stimulators placed externally over the spine or extremity produce a pulsed electromagnetic signal using a coil inserted into a fabric garment worn over the fracture or fusion site (Orthofix) (figure: lower extremity bone stimulator). Extenal low-intensity ultrasound bone growth stimulators are also alvailable for treatment of fracture nonunion (MHCP; Exogen).
