Fracture Fixation

by Tim B Hunter, MD, MSc


Conservative Fracture Treatment

Conservative fracture treatment consists of closed reduction to restore bone alignment and produce bone and soft tissue stabilization. It is achieved either by external splinting (splints and casts) or by external or internal traction (Ruedi, 2007; Benjamin, 1994; Wiss, 2013; Berquist, 1995; Freiberg, 2001; Hunter, 2001).


Casts and splints

External fracture immobilization by casts and splints is an everyday occurrence. Large splints composed of metal, airbags, or plastic have been developed to immobilize fractures in the femur and other large bones (figure: femur fracture splinting and traction) (figure: hinged knee brace). Somewhat smaller plaster and metallic splints stabilize fractures in the arm, forearm, hand and wrist, tibia and fibula, and ankle and foot (figure: wrist splint). There are small metallic splints for finger and toe fractures. Specialized splints have even been developed for particular finger and toe injuries (figure: dorsal blocking splint).

Casts and splints are composed of many materials, including plaster of Paris, synthetic casting material, and metal. Plaster of Paris is most frequently used to make splints and casts, because it is inexpensive, easy to mold, "breathable," and absorbent (figure: plaster cast). Synthetic casting materials are lighter and stronger, but they are more expensive and non-absorbent (figure: fiberglass cast).

Casts and splints can be used either for temporary immobilization of an extremity, or they can be used for definitive treatment of an extremity fracture. They are often combined with internal fixation to provide additional support and protection of the extremity. Braces are also used to limit the range of motion of a joint after surgery or after trauma. In many cases, percutaneous pins ("Kirschner or K-wires") (figure: K-wires) are used in combination with a plaster cast to achieve treatment similar to an external fixator, so-called "pins in plaster" (figure: pins in plaster).


External and internal traction devices

Skeletal traction is the pulling on a bone through a pin or wire inserted into the bone. The pulling is used to reduce and stabilize a fracture. It is most commonly used in the lower extremity. Traction devices are applied along the long axis of the bone. They align the bone fragments and provide a degree of stability (figure: traction pin) (figure: femur fracture splinting and traction). Traction devices work only when the bone fragments are still connected to soft tissues. Skeletal traction entails the insertion of either a Kirschner (K)-wire or Steinman pin through the bone. The Kirschner wire has a smaller diameter and produces less injury to the soft tissues than does the Steinman pin, but it requires the use of a tensioned traction bow. Steinman pins come in a variety of sizes. Both Kirschner wires and Steinman pins can be smooth, partially threaded, or fully threaded. The threaded pins are associated with a more traumatic insertion than smooth pins, but they are less likely to loosen over time.

The most common indication for skeletal traction is a femoral fracture (figure: femur fracture traction). Less commonly, skeletal traction is used for humeral fractures as well as some other lower extremity fractures and dislocations. Sometimes, intraoperative skeletal traction is used for the reduction of a distal radius fracture (Ruedi, 2007; Wiss, 2013).

Traction pins for the lower extremity are placed in one of three sites: supracondylar femur, proximal tibia, or in the calcaneus. Possible complications with supracondylar traction are quadriceps injury, neurovascular injury, and infection. Calcaneal traction, while not uncommon, should ideally be avoided, because it has a high infection rate (figure: calcaneal traction). When a traction pin, fixation pin, or fixator pin has been removed from the bone, a lucent, hollow cylindrical track is left in the bone, a so-called ghost tract (figure: calcaneal ghost tract). The indications, technique, and complications with lower extremity traction pins are nicely summarized by Althausen and Hak (Althausen, 2002).

The Suzuki frame and Suzuki fixator are specialized devices for reducing and stabilizing complex intra-articular finger fractures. Rubber bands generate traction between two K-wires placed into the bone on either side of the fracture (figure: Suzuki frame; figure: Suzuki fixator). Other specialized traction devices are also used for finger and wrist traction (figure: finger traction).

Back to Top

External Fixation

An external fixator is an externally applied device with bone screws or pins designed for the stabilization and immobilization of open long bone fractures. It provides fracture fixation based on the principle of splinting. External fixators are the only system that allows the surgeon to control the flexibility of the fixation. External fixators are the standard in treating open fractures with substantial soft-tissue injuries that require vascular procedures, fasciotomy, soft-tissue flaps, or multiple debridements to avoid additional damage to an already compromised limb.

The other indications for the application of an external fixator are polytrauma; fractures in children to avoid pin fixation through the growth plate; temporary joint bridging before later open reduction and internal fixation (ORIF); and arthrodesis of the ankle, elbow, or knee. In these latter cases, external fixators are especially indicated in acute or chronic infections, in limb-lengthening procedures, and occasionally after corrective osteotomies (Ruedi, 2007; Benjamin, 1994; Wiss, 2013; Berquist, 1995; Freiberg, 2001; Hunter, 2001).

External fixators are made of connecting rods with pins, screws, or wires (Schanz screws, Steinman pins, Kirschner wires) that are placed percutaneously into the bone above and below the fracture site. These pins, screws, or wires are connected by various clamps to the external fixation rods which are composed of stainless steel or carbon fiber.

There are three basic types of external fixators: a) standard pin (or uniplanar) fixator (figure: external fixator radius; figure: Stableloc external fixator), b) ring fixator (figure: ring fixator), and c) hybrid fixator (figure: hybrid fixator). Standard uniplanar external fixators consist of percutaneously placed pins that are connected to an external rod. Proper pin or screw placement is very important. These pins or screws should penetrate the near cortex and medullary canal and engage the far cortex without penetrating the muscle compartment. Joint penetration by any of these pins must be avoided. Standard uniplanar fixators can be used for almost every long bone fracture except those involving the proximal femur or humerus. They are commonly used for the stabilization of complex distal radius fractures. The pins are placed in the distal radius and second metacarpal shaft. This technique uses the surrounding soft tissues or ligaments to provide indirect stabilization of the fracture. Uniplanar external fixators have a limited use in temporary stabilization of pelvic fractures (figure: uniplanar pelvis external fixator).

Ring fixators are made of thin wires under tension that are attached to circular or semicircular rings or frames. This technique was introduced by the Russian surgeon Ilizarov for limb-lengthening procedures. Currently, it has broader applications. The term Ilizarov fixator is frequently used for any type of ring fixator (figure: ring fixator) (Ruedi, 2007; Benjamin, 1994; Berquist, 1995; Freiberg, 2001; Hunter, 2001).

The third type of external fixator is called a hybrid fixator (figure: hybrid external fixator). It represents the combination of ring and standard uniplanar fixators. It is commonly used for treatment of the proximal and distal tibial fractures that are close to the joint. This fixator is made of a 3/4 ring proximally, which is attached to the bone by Kirschner wires. The ring is connected to a unilateral external rod, which is attached to the distal bone shaft by Schanz screws.

The adequate care of pin-track sites is important and starts at the day of placement. Daily cleansing and disinfection is necessary to minimize pin-track infection. Radiography is used to evaluate for pin loosening, breakage, and infection. Visualization of the entire device is frequently limited because of the overlapping frame, and additional views and even fluoroscopic evaluation may be needed for adequate assessment of possible complications (Ruedi, 2007; Benjamin, 1994; Wiss, 2013; Berquist, 1995; Freiberg, 2001; Hunter, 2001).

Pinless fixators are sometimes used for tibial fractures but they are less stable. With these fixators, the medullary canal is not penetrated because the clamps (forceps) are anchored into the cortex only. This type of fixation allows later safe intramedullary nailing (Ruedi, 2007).

Back to Top

Metallic wrist splint Fiberglass cast Fiberglass cast
Wrist splint Metallic wrist splint Fiberglass cast Fiberglass cast
50 year-old woman with acute distal radius fracture. From Benjamin, 1994 60 year-old woman with healing distal radius fracture.
Plaster cast Plaster cast Plaster cast Pins in plaster
Plaster cast Plaster cast Plaster cast Pins in plaster
From Benjamin, 1994 50 year-old female with acute distal radius fracture (same patient with the metallic splint). Five K-wires stabilize a distal radius fracture with a cast in place.
Hinged knee brace AP view Hinged knee brace lateral view K-wires AP view K-wires lateral view
Hinged knee brace AP view Hinged knee brace lateral view K-wires in the distal radius K-wires in the wrist
  65 year-old woman with healing patellar fracture stabilized by two cancellous partially threaded bone screws and tension band wires. 50 year-old woman with a distal radius fracture immobilized by 4 Kirschner wires (K-wires). There is also an ulnar styloid fracture.
Traction pin Uniplanar external fixator Stableloc external fixation system Uniplanar pelvis external fixator
Traction pin in knee External fixator Stableloc external fixator Uniplanar pelvis external fixator
There is a Kirschner wire inserted through the proximal tibial diaphysis with an external metallic traction device. External fixator used to treat a distal radius fracture (which also has a percutaneous pin in it). There are unilateral threaded pins in the radius and in the index finger metacarpal. From Benjamin, 1994 This system is designed to stabilize otherwise unstable distal radius fractures. Image from Acumed

Patient with multiple bilateral pelvic fractures. There is a uniplanar fixator with Schantz pins that transfix both iliac bones with carbon-fiber interconnecting rods (arrows). Two cancellous cannulated screws (proximal fully threaded, distal partially threaded with a washer) transfix the right sacroiliac joint and right sacral fracture. There is a reconstruction plate with four fully threaded cortical screws transfixing the posterior wall of the left acetabulum. From Taljanovic, 2005

Hybrid fixator Ring (Ilizarov) external fixator Steinman pins
Hybrid external fixator Hybrid external fixator Ring (Ilizarov) external fixator Steinman pins in shoulder
57 year-old man with chronic fracture deformities treated by tibial and fibular osteotomies and placement of a hybrid external fixator. The fixator stabilizes a healing tibial fracture and a fibular osteotomy. From Taljanovic, 2005 From Taljanovic, 2005
80 year-old woman with left femur fracture stabilized by a femur fracture splint and later by femur fracture traction Dorsal blocking splint
Femur fracture splint Femur fracture traction AP view Femur fracture traction lateral view Dorsal blocking splint
      The patient suffered a volar plate injury to his ring finger from an electrical shock while working on a fish tank!
Suzuki frame Suzuki fixator
Suzuki frame Suzuki frame Suzuki fixator Suzuki fixator
41 year-old man with chronic fracture dislocation of the left ring finger proximal phalanx.   53 year-old woman with comminuted fracture involving the proximal portion of the left little finger middle phalanx.
Finger traction Calcaneal traction Calcaneal ghost tract from removal of traction pin
Finger traction Calcaneal traction Calcaneal ghost track
External traction wire devices have been placed on the 1-4th fingers to reduce and stabilize a distal radius fracture.
